Summary

This guide is designed to assist IT professionals a greater insight into the inner workings of the WAVE software application and how it fits into a new or existing IT infrastructure.

Main Components

Wave consists of the following component applications:

• WAVE Sync - a set of cloud services for remote connectivity and notifications
• WAVE Desktop - a cockpit used to drive the system - a GUI for the system, native application for viewing video and managing the system
• WAVE Mobile - a mobile app for iOS and Android devices
• WAVE Server - a “brain” of the system - discovering cameras, managing devices & users, indexing recording archives, events & rules engine, data synchronization as a system grows, etc.
• Web admin - a web interface for the system, hosted by Wave Server

WAVE Developer Tools

• Server API - a RESTful HTTP API built right into every Wave Server application
• Video Source SDK - for integrating video, audio, and I/O devices
• Storage SDK - for integrating non-standard storage
• Metadata SDK - for video analytics and metadata integration
